Unidirectional Latching MIL-C-26482 Connector 3LO-453C
- PDF spec sheetpdf
- 3D Model3d model
- Print Pageprint page
Description
Model 3LO-453C is a highly reliable latching inertia/impact switch used for various military and commercial aviation applications. The specified g level is preset at the factory. When predetermined g levels are exceeded by the aircraft, this switch will automatically turn on or off certain systems such as: voice or data recording, emergency lighting, and fire control.
-
Specifications
- Sensitivity: Unidirectional
- Contact Type: SPDT
- Contact Rating: 5.0A @ 28 VDC / 125 VAC
- Contact Resistance: Less than 0.5 ohm
- Insulation Resistance: 500 Mohms@500VDC
- Reset: Latching, manual reset
- G Range: 0.5 to 20
- Termination: Connector
- Seal: Hermetic 1 X 10-5 cc/sec
- Accuracy: 10%
- Damping: Undamped
-
Special Features
- Highly reliable & accurate
- Small and Lightweight
- Latching with manual reset
- Cockpit Voice Recorder CVR
- Flight Data Recorder FDR
- Emergency Lighting
- Fire Supression
- Qualified to MIL-STD-810
- No power required
- Ideal for harsh environments
